| Standards and Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
|---|
| Basic Function | Adopts WDM technology
Half/Full-Duplex transfer mode for FX port
Full Duplex Flow Control (IEEE 802.3x)
Half Duplex Flow Control (Backpressure)
Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely
Extends fiber distance up to 20km |
|---|
| Ports | 1 100M SC/UPC port
1 100M RJ45 port (Auto MDI/MDIX) |
|---|
| Wave Length | 1550nm Tx/1310nm Rx |
|---|
| WDM TX | 1550nm |
|---|
| WDM RX | 1310nm |
|---|
| Network Media 10BASE-T | UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m) |
|---|
| Network Media 100BASE-T | UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m) |
|---|
| Network Media 100BASE-FX | Single-mode Fiber |
|---|
| LED Indicators | PWR, FDX/Col, Link/Act, SPD |
|---|
| Dimensions (W*D*H) | 3.7*2.9*1.1 in. (94.5*73.0*27.0 mm) |
|---|
| Power Supply | External Power Adapter |
|---|
| Max Power Consumption | 2.49W |
|---|
| Safety & Emission | FCC, CE, RoHS |
|---|
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
|---|
